AVMATRIX SE1117 H.265/ H.264 SDI STREAMING ENCODER

Opis

1×SDI input, 1×SDI loop out, 1×Analog audio input
Supports H.265/ H.264 stream encode protocol, up to 1080p60hz
Dual-stream (main stream and sub stream)
RTSP, RTP, RTMPS, RTMP, HTTP, UDP, SRT, unicast and multicast
Video and audio streaming or single audio streaming
Image and text overlay
Mirror image & upside-down image
Live stream with no need for connecting a computer

Technical specification:
CONECCTIONS:
• Video Input: SDI x1
• Video Loop Out: SDI x1
• Analog Audio In: 3.5mm(line in)x1
• Network: RJ-45×1(100/1000Mbps self-adaptive Ethernet)

STANDARDS:
• HDMI In Format Support:
1080p 60/59.94/50/30/29.97/25/24/23.98/23.976
1080i 50/59.94/60
720p 60/59.94/50/30/29.97/25/24/23.98
576i 50, 576p 50, 480p 59.94/60, 480i 59.94/60
• Video Coding: H.265/ H.264
• Video Bitrate: 16Kbps ~ 12Mbps
• Audio Coding: ACC/MP3/MP2/G711
• Audio Bitrate: 24Kbps ~ 320Kbps
• Encoding Resolution: 1920×1080, 1680×1056, 1280×720, 1024×576, 960×540, 850×480,
720×576, 720×540, 720×480, 720×404, 720×400, 704×576, 640×480, 640×360
• Encoding Frame Rate: 5-60fps

SYSTEMS:
• Network Protocols: HTTP, RTSP, RTMPS, RTMP, RTP, UDP, Multicast, Unicast, SRT
• Configuration Management: Web configuration, Remote upgrade

OTHERS:
• Consumption: 5w
• Remperature: Working temp: -0℃~40℃, Storage temp: -20℃~70℃
• Dismension (LWD): 104×75.5×24.5mm
• Weight: Net weight: 340g, Gross weight: 730g
• Standard Accessory: 12V 2A power supply
• Optional Accessory: Mounting brackets
